A double sided tape consists of a carrier with adhesive coated on both sides and supplied with a paper or film release liner. Double sided tapes offer dimensional stability when laminated to substrates while offering easy die-cutting properties as well. These constructions can allow different adhesives on each side to bond to substrates requiring a different adhesive.
Some of the typical applications are for industrial and product assembly, mounting, gasketing, splicing and POP displays to name a few.
More common Product Data Sheets below. Other constructions available upon request.
| Product | Carrier | Adhesive | Adhesive Thickness | Liner | |
|---|---|---|---|---|---|
| SB150 | 1 MIL PET | Acrylic | 1.5 MIL/1.5 MIL | Paper | Download |
| SB350 | 1 MIL PET | Acrylic | 3.5 MIL/3.5 MIL | Paper | Download |
| SB455 | 1/2 MIL PET | Acrylic | 1.5 MIL/1.5 MIL | Paper | Download |
| SB455B | 1/2 MIL PET | Acrylic | 1.5 MIL/1.5 MIL | Blue Film | Download |
| SB460 | 1/2 MIL PET | Rubber | 1.4 MIL/1.3 MIL | Paper | Download |
| SB650 | 1/2 MIL PET | Acrylic | 3.0 MIL/3.0 MIL | Paper | Download |
| SB850 | 1/2 MIL PET | Acrylic | 3.5 MIL/2.5 MIL | Red Film | Download |
| SB1225-M | Nylon Nonwoven | Acrylic | 2.0 MIL/3.5 MIL | 2.0 MIL PET | Download |
| SB265 | 0.5 MIL PET | Acrylic/Removable Acrylic | 1.6 MIL/0.8 MIL | Polycoated Kraft | Download |
| SB462 | 0.5 MIL PET | Rubber | 2.0 MIL/2.0 MIL | 92# Polycoated Kraft | Download |
| SB785 | Woven Cotton Cloth | Natural Rubber | --- | Polyethylene Film | Download |
